ELGA MEDICA® 150

MEDICA® 150 – High-Capacity Clinical Water Purification Without Compromise

The MEDICA® 150 is engineered for clinical laboratories that demand both performance and reliability, delivering a powerful water purification solution capable of producing up to 150 liters per hour of CLRW-grade water. Designed specifically for high-volume diagnostic environments, this system ensures an uninterrupted supply of pure, consistent water to multiple clinical analyzers—removing the risk of downtime, protecting sensitive instruments, and guaranteeing accurate results, every single time. Unlike standard laboratory water systems, the MEDICA® 150 combines advanced purification technologies with intelligent monitoring to create a seamless, worry-free user experience. Its integrated recirculation loop prevents stagnation, so every draw is fresh and analyzer-ready. Automated alerts and real-time monitoring keep your team informed of performance and consumable status, avoiding costly interruptions and ensuring compliance with international water quality standards. Compact yet powerful, the MEDICA® 150 minimizes its footprint while maximizing throughput, making it ideal for busy core labs, hospital networks, and reference laboratories that need to run multiple analyzers around the clock. With its built-in redundancy features, service bypass, and long-life consumables, the system drives down operating costs while delivering unmatched reliability.

Key Benefits

• Continuous production of CLRW-grade water at up to 150 L/h
• Supports multiple high-throughput analyzers simultaneously
• Built-in recirculation loop eliminates stagnation and first-draw uncertainty
• Intelligent monitoring and automated alerts ensure full compliance and reliability
• Compact, space-saving design with service bypass for uninterrupted operation
• Extended consumable life reduces cost and maintenance demands

Technical Specifications

Water Quality & Performance

• Make-up Rate: 150 L/hr at 15 °C
• Delivery Flow Rate: Up to 4 L/min @ 14 psi (1 bar)
• Resistivity: 10 MΩ·cm at 25 °C
• TOC (Organics): <30 ppb (typical)
• Bacteria: <1 CFU/ml (typical)
• Particle Filtration: 0.05 µm final filter
• Silica: <0.05 mg/L

Dimensions & Weight

• Height: ~1,000 mm (39.4 in)
• Width: ~600 mm (23.6 in)
• Depth: ~700 mm (27.6 in)
• Supply Weight: ~85–90 kg (depending on configuration)
• Operational Weight: ~110–120 kg

Connections & Utilities

• Power Requirements: 230 V, 50/60 Hz, 13 A
• Feedwater Pressure: 2–6 bar
• Feedwater Temperature: 5–40 °C
• Drain Connection: Required

Compliance & Standards

• CLRW (Clinical Laboratory Reagent Water, CLSI Type 1)
• ISO 9001, ISO 14001 manufacturing standards
